OverlapMatrix class. More...

#include "LArOverlapMatrix.h"

Classes
class	Element
	Element class. More...

Public Types
typedef T	OverlapResult

typedef std::vector< Element >	ElementList

typedef std::unordered_map< const pandora::Cluster *, pandora::ClusterList >	ClusterNavigationMap

typedef std::unordered_map< const pandora::Cluster *, OverlapResult >	OverlapList

typedef std::unordered_map< const pandora::Cluster *, OverlapList >	TheMatrix

typedef TheMatrix::const_iterator	const_iterator

Public Member Functions
void	GetUnambiguousElements (const bool ignoreUnavailable, ElementList &elementList) const
	Get unambiguous elements.

bool	DefaultAmbiguityFunction (const pandora::ClusterList &clusterList1, const pandora::ClusterList &clusterList2, const pandora::Cluster &pCluster1, const pandora::Cluster &pCluster2) const
	Default ambiguity function, checking that only one cluster from view 1 and view 2 is found.

void	GetNConnections (const pandora::Cluster *const pCluster, const bool ignoreUnavailable, unsigned int &n1, unsigned int &n2) const
	Get the number of connections for a specified cluster.

void	GetConnectedElements (const pandora::Cluster *const pCluster, const bool ignoreUnavailable, ElementList &elementList) const
	Get a list of elements connected to a specified cluster.

void	GetConnectedElements (const pandora::Cluster *const pCluster, const bool ignoreUnavailable, ElementList &elementList, unsigned int &n1, unsigned int &n2) const
	Get a list of elements connected to a specified cluster.

const_iterator	begin () const
	Returns an iterator referring to the first element in the overlap matrix.

const_iterator	end () const
	Returns an iterator referring to the past-the-end element in the overlap matrix.

void	GetSortedKeyClusters (pandora::ClusterVector &sortedKeyClusters) const
	Get a sorted vector of key clusters (view 1 clusters with current implementation)

const OverlapResult &	GetOverlapResult (const pandora::Cluster const pCluster1, const pandora::Cluster const pCluster2) const
	Get the overlap result for a specified pair of clusters.

const OverlapList &	GetOverlapList (const pandora::Cluster *const pCluster1) const
	Get the overlap list for a specified cluster.

const ClusterNavigationMap &	GetClusterNavigationMap12 () const
	Get the cluster navigation map 1->2.

const ClusterNavigationMap &	GetClusterNavigationMap21 () const
	Get the cluster navigation map 2->1.

void	SetOverlapResult (const pandora::Cluster const pCluster1, const pandora::Cluster const pCluster2, const OverlapResult &overlapResult)
	Set overlap result.

void	ReplaceOverlapResult (const pandora::Cluster const pCluster1, const pandora::Cluster const pCluster2, const OverlapResult &overlapResult)
	SetReplace an existing overlap result.

void	RemoveCluster (const pandora::Cluster *const pCluster)
	Remove entries from matrix corresponding to specified cluster.

void	Clear ()
	Clear overlap matrix.

Private Member Functions
void	GetConnectedElements (const pandora::Cluster *const pCluster, const bool ignoreUnavailable, ElementList &elementList, pandora::ClusterList &clusterList1, pandora::ClusterList &clusterList2) const
	Get elements connected to a specified cluster.

void	ExploreConnections (const pandora::Cluster *const pCluster, const bool ignoreUnavailable, pandora::ClusterList &clusterList1, pandora::ClusterList &clusterList2) const
	Explore connections associated with a given cluster.

Private Attributes
TheMatrix	m_overlapMatrix
	The overlap matrix.

ClusterNavigationMap	m_clusterNavigationMap12
	The cluster navigation map 1->2.

ClusterNavigationMap	m_clusterNavigationMap21
	The cluster navigation map 2->1.

Detailed Description

template<typename T>
class lar_content::OverlapMatrix< T >

OverlapMatrix class.

Definition at line 23 of file LArOverlapMatrix.h.

Member Typedef Documentation

◆ ClusterNavigationMap

template<typename T >

typedef std::unordered_map<const pandora::Cluster *, pandora::ClusterList> lar_content::OverlapMatrix< T >::ClusterNavigationMap

Definition at line 131 of file LArOverlapMatrix.h.

◆ const_iterator

template<typename T >

typedef TheMatrix::const_iterator lar_content::OverlapMatrix< T >::const_iterator

Definition at line 135 of file LArOverlapMatrix.h.

◆ ElementList

template<typename T >

typedef std::vector<Element> lar_content::OverlapMatrix< T >::ElementList

Definition at line 77 of file LArOverlapMatrix.h.

◆ OverlapList

template<typename T >

typedef std::unordered_map<const pandora::Cluster *, OverlapResult> lar_content::OverlapMatrix< T >::OverlapList

Definition at line 132 of file LArOverlapMatrix.h.

◆ OverlapResult

template<typename T >

typedef T lar_content::OverlapMatrix< T >::OverlapResult

Definition at line 26 of file LArOverlapMatrix.h.

◆ TheMatrix

template<typename T >

typedef std::unordered_map<const pandora::Cluster *, OverlapList> lar_content::OverlapMatrix< T >::TheMatrix

Definition at line 133 of file LArOverlapMatrix.h.

Member Function Documentation

◆ begin()

template<typename T >

OverlapMatrix< T >::const_iterator lar_content::OverlapMatrix< T >::begin ( ) const

inline

Returns an iterator referring to the first element in the overlap matrix.

Definition at line 265 of file LArOverlapMatrix.h.

◆ Clear()

template<typename T >

void lar_content::OverlapMatrix< T >::Clear ( )

inline

Clear overlap matrix.

Definition at line 325 of file LArOverlapMatrix.h.

◆ DefaultAmbiguityFunction()

template<typename T >

bool lar_content::OverlapMatrix< T >::DefaultAmbiguityFunction	(	const pandora::ClusterList &	clusterList1,
		const pandora::ClusterList &	clusterList2,
		const pandora::Cluster *&	pCluster1,
		const pandora::Cluster *&	pCluster2
	)		const

Default ambiguity function, checking that only one cluster from view 1 and view 2 is found.

Parameters

clusterList1	cluster list 1
clusterList2	cluster list 2
pCluster1	to receive the address of the unambiguous cluster 1
pCluster2	to receive the address of the unambiguous cluster 2

Returns: boolean

Definition at line 63 of file LArOverlapMatrix.cc.

◆ end()

template<typename T >

OverlapMatrix< T >::const_iterator lar_content::OverlapMatrix< T >::end ( ) const

inline

Returns an iterator referring to the past-the-end element in the overlap matrix.

Definition at line 273 of file LArOverlapMatrix.h.

◆ ExploreConnections()

template<typename T >

void lar_content::OverlapMatrix< T >::ExploreConnections	(	const pandora::Cluster *const	pCluster,
		const bool	ignoreUnavailable,
		pandora::ClusterList &	clusterList1,
		pandora::ClusterList &	clusterList2
	)		const

private

Explore connections associated with a given cluster.

Parameters

pCluster	address of the cluster
clusterList1	connected view 1 clusters
clusterList2	connected view 2 clusters

Definition at line 235 of file LArOverlapMatrix.cc.

◆ GetClusterNavigationMap12()

template<typename T >

const OverlapMatrix< T >::ClusterNavigationMap & lar_content::OverlapMatrix< T >::GetClusterNavigationMap12 ( ) const

inline

Get the cluster navigation map 1->2.

Returns: the cluster navigation map 1->2

Definition at line 309 of file LArOverlapMatrix.h.

◆ GetClusterNavigationMap21()

template<typename T >

const OverlapMatrix< T >::ClusterNavigationMap & lar_content::OverlapMatrix< T >::GetClusterNavigationMap21 ( ) const

inline

Get the cluster navigation map 2->1.

Returns: the cluster navigation map 2->1

Definition at line 317 of file LArOverlapMatrix.h.

◆ GetConnectedElements() [1/3]

template<typename T >

void lar_content::OverlapMatrix< T >::GetConnectedElements	(	const pandora::Cluster *const	pCluster,
		const bool	ignoreUnavailable,
		ElementList &	elementList
	)		const

inline

Get a list of elements connected to a specified cluster.

Parameters

pCluster	address of a cluster
ignoreUnavailable	whether to ignore unavailable clusters
elementList	to receive the connected element list

Definition at line 256 of file LArOverlapMatrix.h.

◆ GetConnectedElements() [2/3]

template<typename T >

void lar_content::OverlapMatrix< T >::GetConnectedElements	(	const pandora::Cluster *const	pCluster,
		const bool	ignoreUnavailable,
		ElementList &	elementList,
		pandora::ClusterList &	clusterList1,
		pandora::ClusterList &	clusterList2
	)		const

private

Get elements connected to a specified cluster.

Parameters

pCluster	address of the cluster
elementList	the element list
clusterList1	connected view 1 clusters
clusterList2	connected view 2 clusters

Definition at line 198 of file LArOverlapMatrix.cc.

◆ GetConnectedElements() [3/3]

template<typename T >

void lar_content::OverlapMatrix< T >::GetConnectedElements	(	const pandora::Cluster *const	pCluster,
		const bool	ignoreUnavailable,
		ElementList &	elementList,
		unsigned int &	n1,
		unsigned int &	n2
	)		const

Get a list of elements connected to a specified cluster.

Parameters

pCluster	address of a cluster
ignoreUnavailable	whether to ignore unavailable clusters
elementList	to receive the connected element list
n1	to receive the number of view 1 connections
n2	to receive the number of view 2 connections

Definition at line 78 of file LArOverlapMatrix.cc.

◆ GetNConnections()

template<typename T >

void lar_content::OverlapMatrix< T >::GetNConnections	(	const pandora::Cluster *const	pCluster,
		const bool	ignoreUnavailable,
		unsigned int &	n1,
		unsigned int &	n2
	)		const

inline

Get the number of connections for a specified cluster.

Parameters

pCluster	address of a cluster
ignoreUnavailable	whether to ignore unavailable clusters
n1	to receive the number of view 1 connections
n2	to receive the number of view 2 connections

Definition at line 247 of file LArOverlapMatrix.h.

◆ GetOverlapList()

template<typename T >

const OverlapMatrix< T >::OverlapList & lar_content::OverlapMatrix< T >::GetOverlapList ( const pandora::Cluster *const pCluster1 ) const

inline

Get the overlap list for a specified cluster.

Parameters

pCluster1 address of cluster 1

Returns: the cluster overlap list

Definition at line 296 of file LArOverlapMatrix.h.

◆ GetOverlapResult()

template<typename T >

const OverlapMatrix< T >::OverlapResult & lar_content::OverlapMatrix< T >::GetOverlapResult	(	const pandora::Cluster *const	pCluster1,
		const pandora::Cluster *const	pCluster2
	)		const

inline

Get the overlap result for a specified pair of clusters.

Parameters

pCluster1	address of cluster 1
pCluster2	address of cluster 2

Returns: the address of the overlap result

Definition at line 281 of file LArOverlapMatrix.h.

Here is the caller graph for this function:

◆ GetSortedKeyClusters()

template<typename T >

void lar_content::OverlapMatrix< T >::GetSortedKeyClusters ( pandora::ClusterVector & sortedKeyClusters ) const

Get a sorted vector of key clusters (view 1 clusters with current implementation)

Parameters

sortedKeyClusters to receive the sorted vector of key clusters

Definition at line 90 of file LArOverlapMatrix.cc.

Here is the call graph for this function:

◆ GetUnambiguousElements()

template<typename T >

void lar_content::OverlapMatrix< T >::GetUnambiguousElements	(	const bool	ignoreUnavailable,
		ElementList &	elementList
	)		const

Get unambiguous elements.

Parameters

ignoreUnavailable	whether to ignore unavailable clusters
elementList	to receive the unambiguous element list

Definition at line 30 of file LArOverlapMatrix.cc.

◆ RemoveCluster()

template<typename T >

void lar_content::OverlapMatrix< T >::RemoveCluster ( const pandora::Cluster *const pCluster )

Remove entries from matrix corresponding to specified cluster.

Parameters

pCluster address of the cluster

Definition at line 142 of file LArOverlapMatrix.cc.

◆ ReplaceOverlapResult()

template<typename T >

void lar_content::OverlapMatrix< T >::ReplaceOverlapResult	(	const pandora::Cluster *const	pCluster1,
		const pandora::Cluster *const	pCluster2,
		const OverlapResult &	overlapResult
	)

SetReplace an existing overlap result.

Parameters

pCluster1	address of cluster 1
pCluster2	address of cluster 2
overlapResult	the overlap result

Definition at line 124 of file LArOverlapMatrix.cc.

◆ SetOverlapResult()

template<typename T >

void lar_content::OverlapMatrix< T >::SetOverlapResult	(	const pandora::Cluster *const	pCluster1,
		const pandora::Cluster *const	pCluster2,
		const OverlapResult &	overlapResult
	)

Set overlap result.

Parameters

pCluster1	address of cluster 1
pCluster2	address of cluster 2
overlapResult	the overlap result

Definition at line 101 of file LArOverlapMatrix.cc.

Member Data Documentation

◆ m_clusterNavigationMap12

template<typename T >

ClusterNavigationMap lar_content::OverlapMatrix< T >::m_clusterNavigationMap12

private

The cluster navigation map 1->2.

Definition at line 240 of file LArOverlapMatrix.h.

◆ m_clusterNavigationMap21

template<typename T >

ClusterNavigationMap lar_content::OverlapMatrix< T >::m_clusterNavigationMap21

private

The cluster navigation map 2->1.

Definition at line 241 of file LArOverlapMatrix.h.

◆ m_overlapMatrix

template<typename T >

TheMatrix lar_content::OverlapMatrix< T >::m_overlapMatrix

private

The overlap matrix.

Definition at line 239 of file LArOverlapMatrix.h.

The documentation for this class was generated from the following files:

LArContent/larpandoracontent/LArObjects/LArOverlapMatrix.h
LArContent/larpandoracontent/LArObjects/LArOverlapMatrix.cc

Classes

Public Types

Public Member Functions

Private Member Functions

Private Attributes

Detailed Description

Member Typedef Documentation

◆ ClusterNavigationMap

◆ const_iterator

◆ ElementList

◆ OverlapList

◆ OverlapResult

◆ TheMatrix

Member Function Documentation

◆ begin()

◆ Clear()

◆ DefaultAmbiguityFunction()

◆ end()

◆ ExploreConnections()

◆ GetClusterNavigationMap12()

◆ GetClusterNavigationMap21()

◆ GetConnectedElements() [1/3]

◆ GetConnectedElements() [2/3]

◆ GetConnectedElements() [3/3]

◆ GetNConnections()

◆ GetOverlapList()

◆ GetOverlapResult()

◆ GetSortedKeyClusters()

◆ GetUnambiguousElements()

◆ RemoveCluster()

◆ ReplaceOverlapResult()

◆ SetOverlapResult()

Member Data Documentation

◆ m_clusterNavigationMap12

◆ m_clusterNavigationMap21

◆ m_overlapMatrix
